Body |
Base model |
SUZUKI XL7 |
Frame |
Steel space frame |
Cowl |
Carbon and Kevlar composite |
Front wing & Rear wing |
Carbon and Kevlar composite |
Aerodynamics |
Front: |
Under wing + Canard wing |
Rear: |
Diffuser + 3 wings |
Engine |
Model |
N36A |
Type |
Liquid cooled V6 4 valves DOHC + 2 turbo, dry sump |
Bore x stroke |
94.0×85.6mm |
Capacity |
3564cc |
Maximum horsepower（Net） |
1007ps/8500r.p.m (Sea level) |
Maximum torque |
102.0kg-m/6250r.p.m（Sea level） |
Oil |
Mobil 1 Full Synthetic |
Oil Filter |
POWER FILTER Ti100 |
Sparking Plug |
NGK Racing |
Air Filter |
POWER FILTER PFX600 |
Intercooler |
ARC |
Radiator |
ARC |
Power train |
Gearbox |
Sequential 6-speed |
Differential |
Front/Rear: Hydraulic Controlled ,Center: Mechanical multi plate |
Clutch |
EXEDY Triple plate direct release |
Suspension |
Type |
Front/Rear: Double wishbone |
Brake |
Disc |
Front: Dia.370mm ventilated / Rear: Dia.350mm ventilated |
Caliper |
Front: 8 pot / Rear: 8 pot |
Pad/Facing |
Front: Winmax Pikes Peak Special / Rear: Winmax Pikes Peak Special |
Tire&Wheel |
Tire |
Front/Rear: 285/60R18 FALKEN S/TZ04 Pikes Peak Special |
Wheel |
Front/Rear: 18 x 11J RAYS CE28N |
Dimensions *without front and rear wing |
Length |
5300mm |
Width |
1960mm (without front Canard) |
Height |
1500mm |
Wheelbase |
2818mm |
Tread |
Front: 1620mm / Rear: 1610mm |
Weight |
Race weight（without driver, fuel） |
1100kg |
Start weight |
1,190kg |
Weight distribution（with driver） |
Front: 53 / Rear: 47 |
